MD2310FX
RoHS
RoHS compliant
RoHS compliantPackage ISOWATT218FX
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 700V 14A TO-3PF
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥30 USD $2.13465
≥100 USD $2.0653
≥500 USD $1.9969
≥1000 USD $1.7898
Inventory: 6501
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case ISOWATT218FX
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Transistors
Max Power Dissipation 62W
Base Part Number MD2310
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 62W
Case Connection ISOLATED
Transistor Application AMPLIFIER
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 700V
Max Collector Current 14A
DC Current Gain (hFE) (Min) @ Ic, Vce 6 @ 7A 5V
Current - Collector Cutoff (Max) 200μA
Vce Saturation (Max) @ Ib, Ic 2.5V @ 1.75A, 7A
Collector Emitter Breakdown Voltage 700V
Max Frequency 64kHz
Collector Emitter Saturation Voltage 2.5V
Collector Base Voltage (VCBO) 1.5kV
Emitter Base Voltage (VEBO) 9V
hFE Min 6
Isolation Voltage 2.5kV
Dimensions
Height 26.7mm
Length 15.7mm
Width 5.7mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
