HD1750JL
RoHS
RoHS compliant
RoHS compliantPackage TO-264-3, TO-264AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 800V 24A TO-264
PDF
/
Inventory: 8431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-264-3, TO-264AA
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Transistors
Max Power Dissipation 200W
Base Part Number HD1750
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 200W
Transistor Application AMPLIFIER
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 800V
Max Collector Current 24A
DC Current Gain (hFE) (Min) @ Ic, Vce 5.5 @ 12A 5V
Current - Collector Cutoff (Max) 200μA
Vce Saturation (Max) @ Ib, Ic 3V @ 3A, 12A
Collector Emitter Breakdown Voltage 800V
Emitter Base Voltage (VEBO) 10V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
