HD1530JL
RoHS
RoHS compliant
RoHS compliantPackage TO-264-3, TO-264AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 700V 26A TO-264
PDF
/
Inventory: 6536
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Emitter Base Voltage (VEBO) 10V
Collector Emitter Breakdown Voltage 700V
Vce Saturation (Max) @ Ib, Ic 2.5V @ 3.25A, 13A
Current - Collector Cutoff (Max) 200μA
DC Current Gain (hFE) (Min) @ Ic, Vce 5 @ 13A 5V
Max Collector Current 26A
Collector Emitter Voltage (VCEO) 700V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application AMPLIFIER
Power Dissipation 200W
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number HD1531
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 225
Max Power Dissipation 200W
Subcategory Other Transistors
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-264-3, TO-264AA
Mounting Type Through Hole
Mount Through Hole
