ESM4045DV
RoHS
RoHS compliant
RoHS compliantPackage ISOTOP
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN DARL 450V 42A ISOTOP
PDF
/
Inventory: 9171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case ISOTOP
Number of Pins 4
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Nickel (Ni)
Subcategory BIP General Purpose Power
Voltage - Rated DC 450V
Max Power Dissipation 150W
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 42A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number ESM4045
Pin Count 4
Qualification Status Not Qualified
Number of Elements 1
Polarity NPN
Configuration DARLINGTON WITH BUILT-IN DIODE
Case Connection ISOLATED
Transistor Application SWITCHING
Transistor Type NPN - Darlington
Collector Emitter Voltage (VCEO) 450V
Max Collector Current 42A
DC Current Gain (hFE) (Min) @ Ic, Vce 220 @ 35A 5V
Vce Saturation (Max) @ Ib, Ic 1.4V @ 2A, 35A
Collector Emitter Breakdown Voltage 450V
Collector Emitter Saturation Voltage 2V
Emitter Base Voltage (VEBO) 7V
hFE Min 220
VCEsat-Max 2 V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
