D45H11
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole PNP Single Bipolar (BJT) Transistor 40 @ 4A 1V 10muA 50W 40MHz
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $0.874368
≥100 USD $0.692824
≥500 USD $0.587259
≥1000 USD $0.478386
≥3000 USD $0.450349
Inventory: 1322
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 4.535924g
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Transistors
Voltage - Rated DC -80V
Max Power Dissipation 50W
Current Rating -10A
Base Part Number D45H11
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 50W
Case Connection COLLECTOR
Transistor Application SWITCHING
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 80V
Max Collector Current 10A
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 4A 1V
Current - Collector Cutoff (Max) 10μA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 1V @ 400mA, 8A
Collector Emitter Breakdown Voltage 80V
Transition Frequency 40MHz
Collector Emitter Saturation Voltage 1V
Collector Base Voltage (VCBO) 80V
Emitter Base Voltage (VEBO) 5V
hFE Min 60
VCEsat-Max 1 V
Dimensions
Height 15.75mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
