BUX348
RoHS
RoHS compliant
RoHS compliantPackage TO-204AA, TO-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT NPN 450V 45A 3-Pin(2+Tab) TO-3 Tube
PDF
/
Buying Options
Total Price: USD $20.19
Unit Price: USD $20.19035
≥1 USD $20.19035
≥10 USD $16.5661
≥100 USD $16.0493
≥500 USD $15.53155
≥1000 USD $15.0138
Inventory: 1529
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-204AA, TO-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 200°C TJ
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Other Transistors
Voltage - Rated DC 450V
Max Power Dissipation 300W
Terminal Position BOTTOM
Terminal Form PIN/PEG
Current Rating 45A
Base Part Number BUX348
Pin Count 2
JESD-30 Code O-MBFM-P2
Number of Elements 1
Element Configuration Single
Power Dissipation 300W
Case Connection COLLECTOR
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 450V
Max Collector Current 45A
Vce Saturation (Max) @ Ib, Ic 900mV @ 6A, 30A
Collector Emitter Breakdown Voltage 450V
Collector Emitter Saturation Voltage 700mV
Collector Base Voltage (VCBO) 850V
Emitter Base Voltage (VEBO) 7V
VCEsat-Max 0.9 V
Turn Off Time-Max (toff) 4900ns
Dimensions
Height 8.7mm
Length 39.5mm
Width 26.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
