BUT11A
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN Single Bipolar (BJT) Transistor 10 @ 500mA 5V 1mA 83W 1kV
PDF
/
Buying Options
Total Price: USD $1.48
Unit Price: USD $1.4784
≥1 USD $1.4784
≥10 USD $1.23112
≥100 USD $0.979748
≥500 USD $0.829022
Inventory: 947
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
hFE Min 10
Emitter Base Voltage (VEBO) 9V
Collector Base Voltage (VCBO) 1kV
Collector Emitter Saturation Voltage 1.5V
Collector Emitter Breakdown Voltage 450V
Vce Saturation (Max) @ Ib, Ic 1.5V @ 500mA, 2.5A
Current - Collector Cutoff (Max) 1mA
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 500mA 5V
Max Collector Current 5A
Collector Emitter Voltage (VCEO) 450V
Transistor Type NPN
Power Dissipation 83W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number BUT11
Current Rating 5A
Max Power Dissipation 83W
Voltage - Rated DC 450V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tube
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
