BUL310
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 500V 5A TO-220
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.32525
≥1 USD $1.32525
≥10 USD $1.08775
≥100 USD $1.05355
≥500 USD $1.01935
≥1000 USD $0.9861
Inventory: 1195
Minimum: 1
-
+
Technical Details
Technical
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature HIGH RELIABILITY
Subcategory Other Transistors
Voltage - Rated DC 500V
Max Power Dissipation 75W
Current Rating 5A
Base Part Number BUL310
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 75W
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 500V
Max Collector Current 5A
DC Current Gain (hFE) (Min) @ Ic, Vce 6 @ 3A 2.5V
Current - Collector Cutoff (Max) 250μA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 1.1V @ 600mA, 3A
Collector Emitter Breakdown Voltage 500V
Collector Emitter Saturation Voltage 1.1V
Collector Base Voltage (VCBO) 1kV
Emitter Base Voltage (VEBO) 9V
hFE Min 6
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Dimensions
Height 9.15mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
