BU931T
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans Darlington NPN 400V 15A Automotive 3-Pin(3+Tab) TO-220 Tube
PDF
/
Buying Options
Total Price: USD $4.73
Unit Price: USD $4.727654
≥1 USD $4.727654
≥10 USD $4.169074
≥100 USD $3.653663
≥500 USD $4.1306
≥1000 USD $3.99285
≥1000 USD $3.58055
Inventory: 13
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 15.75mm
Technical
hFE Min 300
Emitter Base Voltage (VEBO) 5V
Collector Emitter Saturation Voltage 1.8V
Collector Emitter Breakdown Voltage 400V
Vce Saturation (Max) @ Ib, Ic 1.8V @ 250mA, 10A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 100μA
DC Current Gain (hFE) (Min) @ Ic, Vce 300 @ 5A 10V
Max Collector Current 10A
Collector Emitter Voltage (VCEO) 400V
Transistor Type NPN - Darlington
Transistor Application SWITCHING
Case Connection COLLECTOR
Power Dissipation 125W
Element Configuration Single
Polarity NPN
Number of Elements 1
Pin Count 3
Base Part Number BU931
Current Rating 10A
Max Power Dissipation 125W
Voltage - Rated DC 400V
Subcategory Other Transistors
Additional Feature BUILT-IN BIAS RESISTORS
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101
Packaging Tube
Operating Temperature 175°C TJ
Physical
Transistor Element Material SILICON
Weight 45.359237mg
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 8 Weeks
