BU807
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN - Darlington Single Bipolar (BJT) Transistor 1.5V @ 50mA 5A 8A 60W 1000ns
PDF
/
Buying Options
Total Price: USD $15.73
Unit Price: USD $15.7301
≥1 USD $15.7301
≥10 USD $12.9067
≥100 USD $12.5039
≥500 USD $12.10015
≥1000 USD $11.69735
Inventory: 1926
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Turn Off Time-Max (toff) 1000ns
VCEsat-Max 1.5 V
Continuous Collector Current 8A
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 330V
Collector Emitter Breakdown Voltage 150V
Vce Saturation (Max) @ Ib, Ic 1.5V @ 50mA, 5A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 100μA
Max Collector Current 8A
Collector Emitter Voltage (VCEO) 150V
Transistor Type NPN - Darlington
Transistor Application SWITCHING
Case Connection ISOLATED
Power Dissipation 60W
Element Configuration Single
Polarity NPN
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number BU807
Current Rating 8A
Max Power Dissipation 60W
Voltage - Rated DC 400V
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
