BU406
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN Single Bipolar (BJT) Transistor 1V @ 500mA 5A 5mA 60W 10MHz
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.286825
≥1 USD $0.286825
≥10 USD $0.226258
≥100 USD $0.202711
≥500 USD $0.143321
≥1000 USD $0.132529
≥5000 USD $0.126054
Inventory: 23
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
Turn Off Time-Max (toff) 750ns
VCEsat-Max 1 V
DC Current Gain-Min (hFE) 10
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 400V
Collector Emitter Saturation Voltage 1V
Transition Frequency 10MHz
Collector Emitter Breakdown Voltage 200V
Vce Saturation (Max) @ Ib, Ic 1V @ 500mA, 5A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 5mA
Max Collector Current 7A
Collector Emitter Voltage (VCEO) 200V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 10MHz
Transistor Application SWITCHING
Power Dissipation 60W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number BU406
Frequency 10MHz
Current Rating 7A
Max Power Dissipation 60W
Voltage - Rated DC 150V
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
