BDW93C
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN - Darlington Single Bipolar (BJT) Transistor 750 @ 5A 3V 1mA 80W 100V
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 205
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Transistors
Voltage - Rated DC 100V
Max Power Dissipation 80W
Current Rating 12A
Base Part Number BDW93
Pin Count 3
Number of Elements 1
Polarity NPN
Element Configuration Single
Power Dissipation 80W
Transistor Application SWITCHING
Transistor Type NPN - Darlington
Collector Emitter Voltage (VCEO) 100V
Max Collector Current 12A
DC Current Gain (hFE) (Min) @ Ic, Vce 750 @ 5A 3V
Current - Collector Cutoff (Max) 1mA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 3V @ 100mA, 10A
Collector Emitter Breakdown Voltage 100V
Collector Emitter Saturation Voltage 2V
Collector Base Voltage (VCBO) 100V
Emitter Base Voltage (VEBO) 2.5V
hFE Min 100
VCEsat-Max 3 V
Dimensions
Height 9.15mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
