BD437
RoHS
RoHS compliant
RoHS compliantPackage TO-225AA, TO-126-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT NPN 45V 4A 3-Pin(3+Tab) SOT-32 Tube
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.666864
≥100 USD $0.484
≥500 USD $0.404413
≥1000 USD $0.344186
≥3000 USD $0.306539
Inventory: 4090
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 2.7mm
Length 7.8mm
Height 10.8mm
Technical
VCEsat-Max 0.6 V
hFE Min 30
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 45V
Collector Emitter Saturation Voltage 200mV
Transition Frequency 3MHz
Collector Emitter Breakdown Voltage 45V
Vce Saturation (Max) @ Ib, Ic 600mV @ 200mA, 2A
Current - Collector Cutoff (Max) 100μA
DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 10mA 5V
Max Collector Current 4A
Collector Emitter Voltage (VCEO) 45V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 3MHz
Transistor Application SWITCHING
Case Connection ISOLATED
Power Dissipation 36W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number BD437
Frequency 3MHz
Max Power Dissipation 36W
Subcategory Other Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-225AA, TO-126-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status NRND (Last Updated: 8 months ago)
