BD239C
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
BD239C Series 100 V 2 A Surface Mount NPN Power Transistor - TO-220-3
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.84392
≥100 USD $0.65626
≥500 USD $0.556248
≥1000 USD $0.45313
≥3000 USD $0.426571
Inventory: 712
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
VCEsat-Max 0.7 V
hFE Min 40
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 115V
Collector Emitter Saturation Voltage 700mV
Collector Emitter Breakdown Voltage 100V
Vce Saturation (Max) @ Ib, Ic 700mV @ 200mA, 1A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 300μA
DC Current Gain (hFE) (Min) @ Ic, Vce 15 @ 1A 4V
Max Collector Current 2A
Collector Emitter Voltage (VCEO) 100V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power Dissipation 2W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number BD239
Max Power Dissipation 2W
Subcategory Other Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 8 Weeks
