BC857B
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount PNP Single Bipolar (BJT) Transistor 220 @ 2mA 5V 15nA ICBO 250mW 100MHz
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.05984
≥100 USD $0.032296
≥500 USD $0.025344
≥1000 USD $0.0176
Inventory: 1546
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
hFE Min 220
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 50V
Max Breakdown Voltage 45V
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage 45V
Vce Saturation (Max) @ Ib, Ic 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 15nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 220 @ 2mA 5V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 45V
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 100MHz
Transistor Application SWITCHING
Power - Max 250mW
Element Configuration Single
Number of Elements 1
Base Part Number BC857
Current Rating -100mA
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 250mW
Voltage - Rated DC -50V
Subcategory Other Transistors
HTS Code 8541.21.00.95
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
