2STR2230
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
POWER BJT, PNP, -30V, -1.5A, SOT-23 - More Details
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.31592
≥100 USD $0.189376
≥500 USD $0.175314
≥1000 USD $0.119214
Inventory: 301
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.3mm
Length 2.9mm
Height 950μm
Technical
hFE Min 70
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 30V
Max Breakdown Voltage 30V
Collector Emitter Saturation Voltage -420mV
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage -30V
Vce Saturation (Max) @ Ib, Ic 800mV @ 200mA, 2A
Current - Collector Cutoff (Max) 100nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 170 @ 500mA 2V
Max Collector Current 1.5A
Collector Emitter Voltage (VCEO) 30V
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 100MHz
Transistor Application SWITCHING
Power Dissipation 500mW
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number 2STR
Time@Peak Reflow Temperature-Max (s) 30
Frequency 100MHz
Current Rating -1.5A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 500mW
Voltage - Rated DC -30V
Subcategory Other Transistors
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 8 Weeks
