2STP535FP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans Darlington NPN 180V 8A 3-Pin(3+Tab) TO-220FP Tube
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.056
≥1 USD $1.056
≥10 USD $0.847616
≥100 USD $0.6974
≥500 USD $0.62964
Inventory: 991
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Additional Feature BUILT IN BIAS RESISTOR
Subcategory Other Transistors
Max Power Dissipation 37W
Base Part Number 2STP
Pin Count 3
Number of Elements 1
Polarity NPN
Element Configuration Single
Case Connection ISOLATED
Power - Max 37W
Transistor Application SWITCHING
Transistor Type NPN - Darlington
Collector Emitter Voltage (VCEO) 180V
Max Collector Current 8A
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 3A 4V
Current - Collector Cutoff (Max) 50μA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 2.5V @ 80mA, 8A
Collector Emitter Breakdown Voltage 180V
Collector Emitter Saturation Voltage 2V
Max Breakdown Voltage 180V
Collector Base Voltage (VCBO) 180V
Emitter Base Voltage (VEBO) 5V
hFE Min 200
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
