2STN1360
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 60V 3A SOT-223
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.4928
≥1 USD $0.4928
≥10 USD $0.4224
≥100 USD $0.293744
≥500 USD $0.229328
Inventory: 1140
Minimum: 1
-
+
Technical Details
Technical
Gain Bandwidth Product 130MHz
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 60V
Max Collector Current 3A
DC Current Gain (hFE) (Min) @ Ic, Vce 160 @ 1A 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 150mA, 3A
Collector Emitter Breakdown Voltage 60V
Transition Frequency 130MHz
Collector Emitter Saturation Voltage 500mV
Max Breakdown Voltage 60V
Collector Base Voltage (VCBO) 80V
Emitter Base Voltage (VEBO) 6V
hFE Min 80
Transistor Application SWITCHING
Case Connection COLLECTOR
Power Dissipation 1.6W
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PDSO-G4
Pin Count 4
Base Part Number 2STN
Time@Peak Reflow Temperature-Max (s) 30
Frequency 130MHz
Current Rating 3A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 1.6W
Voltage - Rated DC 80V
Subcategory Other Transistors
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Dimensions
Height 1.8mm
Length 6.5mm
Width 3.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-261-4, TO-261AA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 8 Weeks
