2STD1665T4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 65V 6A DPAK
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.6952
≥100 USD $0.48136
≥500 USD $0.402195
≥1000 USD $0.342294
Inventory: 1692
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.2mm
Length 6.6mm
Height 2.4mm
Technical
hFE Min 150
Emitter Base Voltage (VEBO) 7V
Collector Base Voltage (VCBO) 150V
Max Breakdown Voltage 65V
Collector Emitter Saturation Voltage 600mV
Collector Emitter Breakdown Voltage 65V
Vce Saturation (Max) @ Ib, Ic 380mV @ 300mA, 6A
Current - Collector Cutoff (Max) 50nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 150 @ 2A 1V
Max Collector Current 6A
Collector Emitter Voltage (VCEO) 65V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power Dissipation 15W
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number 2STD1665
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 6A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Max Power Dissipation 15W
Voltage - Rated DC 150V
Subcategory Other Transistors
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 8 Weeks
