2N4033
RoHS
RoHS compliant
RoHS compliantPackage TO-205AD, TO-39-3 Metal Can
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 80V 1A TO-39
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 19003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 9.4mm
Length 9.4mm
Height 6.6mm
Technical
Turn Off Time-Max (toff) 400ns
hFE Min 100
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 80V
Collector Emitter Saturation Voltage -500mV
Transition Frequency 150MHz
Collector Emitter Breakdown Voltage 80V
Vce Saturation (Max) @ Ib, Ic 500mV @ 50mA, 500mA
Current - Collector Cutoff (Max) 50nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA 5V
Max Collector Current 1A
Collector Emitter Voltage (VCEO) 80V
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 500MHz
Power Dissipation 800mW
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number 2N40
Frequency 500MHz
Current Rating -1A
Terminal Form WIRE
Terminal Position BOTTOM
Max Power Dissipation 800mW
Voltage - Rated DC -80V
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature 175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-205AD, TO-39-3 Metal Can
Mounting Type Through Hole
Mount Through Hole
