2N3700 image
Favorite
2N3700 image
Favorite
RoHS
RoHS RoHS compliant
Package TO-206AA, TO-18-3 Metal Can
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description Tube Through Hole NPN 3 Bipolar (BJT) Transistor 100 @ 150mA 10V 1A 500mW 100MHz
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.1976
≥1 USD $4.1976
≥10 USD $3.8896
Inventory: 287
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Frequency - Transition 100MHz
Current - Collector (Ic) (Max) 1A
Voltage - Collector Emitter Breakdown (Max) 80V
Vce Saturation (Max) @ Ib, Ic 500mV @ 50mA, 500mA
Current - Collector Cutoff (Max) 10nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA 10V
Transistor Type NPN
Power - Max 500mW
Pin Count 3
Base Part Number 2N37
HTS Code 8541.21.00.95
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Packaging Tube
Operating Temperature -65°C~200°C TJ

Physical

Package / Case TO-206AA, TO-18-3 Metal Can
Mounting Type Through Hole
