2SC4304
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 800V 3A TO220F
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 1003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Frequency - Transition 15MHz
Transition Frequency 15MHz
Collector Emitter Breakdown Voltage 800V
Vce Saturation (Max) @ Ib, Ic 500mV @ 140mA, 700mA
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 100μA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 700mA 4V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 500mV
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power - Max 35W
Case Connection ISOLATED
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Max Power Dissipation 35W
Subcategory Other Transistors
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 1999
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
