2SD2654TLV
RoHS
RoHS compliant
RoHS compliantPackage SC-75, SOT-416
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN Single Bipolar (BJT) Transistor 820 @ 1mA 5V 150mA 150mW 250MHz
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.3124
≥100 USD $0.187176
≥500 USD $0.173325
≥1000 USD $0.117858
Inventory: 3159
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Continuous Collector Current 150mA
hFE Min 820
Emitter Base Voltage (VEBO) 12V
Collector Base Voltage (VCBO) 60V
Max Breakdown Voltage 50V
Transition Frequency 250MHz
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 300mV @ 5mA, 50mA
Current - Collector Cutoff (Max) 300nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 820 @ 1mA 5V
Max Collector Current 150mA
Collector Emitter Voltage (VCEO) 50V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 250MHz
Power Dissipation 150mW
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number 2SD2654
Time@Peak Reflow Temperature-Max (s) 10
Frequency 250MHz
Current Rating 150mA
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 150mW
Voltage - Rated DC 50V
Subcategory Other Transistors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case SC-75, SOT-416
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Silver, Tin
Supply Chain
Factory Lead Time 13 Weeks
