2SD1733TLR
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 80V 1A SOT-428
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.355817
≥1 USD $0.355817
≥10 USD $0.31788
≥100 USD $0.298258
≥500 USD $0.279944
≥1000 USD $0.231543
≥1000 USD $0.225002
Inventory: 3878
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Continuous Collector Current 1A
hFE Min 120
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 120V
Max Breakdown Voltage 80V
Collector Emitter Saturation Voltage 150mV
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage 80V
Vce Saturation (Max) @ Ib, Ic 400mV @ 20mA, 500mA
Current - Collector Cutoff (Max) 1μA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 500mA 3V
Max Collector Current 1A
Collector Emitter Voltage (VCEO) 80V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 100MHz
Transistor Application SWITCHING
Power Dissipation 1W
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number 2SD1733
Time@Peak Reflow Temperature-Max (s) 10
Frequency 100MHz
Current Rating 1A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Max Power Dissipation 10W
Voltage - Rated DC 80V
Subcategory Other Transistors
Terminal Finish Tin/Copper (Sn98Cu2)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e2
Published 1998
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Tin
Supply Chain
Factory Lead Time 21 Weeks
