2SC5916TLQ
RoHS
RoHS compliant
RoHS compliantPackage SC-96
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 30V 2A TSMT3
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
hFE Min 120
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 30V
Max Breakdown Voltage 30V
Transition Frequency 250MHz
Collector Emitter Breakdown Voltage 30V
Vce Saturation (Max) @ Ib, Ic 400mV @ 100mA, 1A
Current - Collector Cutoff (Max) 1μA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 100mA 2V
Max Collector Current 2A
Collector Emitter Voltage (VCEO) 400mV
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 250MHz
Transistor Application SWITCHING
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number 2SC5916
Time@Peak Reflow Temperature-Max (s) 10
Current Rating 2A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 500mW
Voltage - Rated DC 30V
Subcategory Other Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case SC-96
Mounting Type Surface Mount
Mount Surface Mount
