2SC4672T100P
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 50V 2A SOT-89
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.6336
≥1 USD $0.6336
≥10 USD $0.54912
≥100 USD $0.379984
≥500 USD $0.317486
Inventory: 1161
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
VCEsat-Max 0.35 V
hFE Min 82
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 60V
Max Breakdown Voltage 50V
Transition Frequency 210MHz
Current - Collector (Ic) (Max) 2A
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 350mV @ 50mA, 1A
Current - Collector Cutoff (Max) 100nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 82 @ 500mA 2V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 50V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 210MHz
Transistor Application AMPLIFIER
Case Connection COLLECTOR
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-F3
Pin Count 3
Base Part Number 2SC4672
Time@Peak Reflow Temperature-Max (s) 10
Current Rating 3A
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Max Power Dissipation 500mW
Voltage - Rated DC 50V
Subcategory Other Transistors
Terminal Finish TIN COPPER
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e2
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 4
Package / Case TO-243AA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Tin
