2SC4102U3HZGT106S
RoHS
RoHS compliant
RoHS compliantPackage SC-70, SOT-323
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
HIGH-VOLTAGE AMPLIFIER TRANSISTO
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.28424
≥100 USD $0.170368
≥500 USD $0.157766
≥1000 USD $0.107281
Inventory: 1179
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Surface Mount YES
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Cut Tape (CT)
Series Automotive, AEC-Q101
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G3
Number of Elements 1
Configuration SINGLE
Power - Max 200mW
Transistor Application AMPLIFIER
Polarity/Channel Type NPN
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 270 @ 2mA 6V
Current - Collector Cutoff (Max) 500nA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 1mA, 10mA
Voltage - Collector Emitter Breakdown (Max) 120V
Current - Collector (Ic) (Max) 50mA
Transition Frequency 140MHz
Frequency - Transition 140MHz
Compliance
RoHS Status ROHS3 Compliant
