2SAR513PT100
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 50V 1A MPT3
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.74624
≥100 USD $0.580448
Inventory: 358
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
hFE Min 180
Emitter Base Voltage (VEBO) -6V
Collector Base Voltage (VCBO) -50V
Max Breakdown Voltage 50V
Collector Emitter Saturation Voltage -200mV
Transition Frequency 400MHz
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 400mV @ 25mA, 500mA
Current - Collector Cutoff (Max) 1μA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 50mA 2V
Max Collector Current 1A
Collector Emitter Voltage (VCEO) 400mV
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 400MHz
Transistor Application SWITCHING
Power - Max 2W
Case Connection COLLECTOR
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Max Power Dissipation 2W
Subcategory Other Transistors
Terminal Finish TIN COPPER
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e2
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-243AA
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
