RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN SINGLE Bipolar (BJT) Transistor 30 @ 300mA 10V 1A 40W 10MHz
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.633424
≥100 USD $0.459712
≥500 USD $0.384155
≥1000 USD $0.326938
≥3000 USD $0.291183
Inventory: 2548
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Bulk
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish TIN LEAD
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 240
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Power - Max 40W
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 300mA 10V
Current - Collector Cutoff (Max) 1mA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 1V @ 200mA, 1A
Voltage - Collector Emitter Breakdown (Max) 250V
Current - Collector (Ic) (Max) 1A
Transition Frequency 10MHz
Frequency - Transition 10MHz
Compliance
RoHS Status ROHS3 Compliant
