TIP42C
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole PNP SINGLE Bipolar (BJT) Transistor 15 @ 3A 4V 6A 2W 3MHz
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.0208
≥1 USD $1.0208
≥10 USD $0.968
≥100 USD $0.9152
≥500 USD $0.8712
≥1000 USD $0.8448
Inventory: 244
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Frequency - Transition 3MHz
Transition Frequency 3MHz
Current - Collector (Ic) (Max) 6A
Voltage - Collector Emitter Breakdown (Max) 100V
Vce Saturation (Max) @ Ib, Ic 1.5V @ 600mA, 6A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 700μA
DC Current Gain (hFE) (Min) @ Ic, Vce 15 @ 3A 4V
Transistor Type PNP
Polarity/Channel Type PNP
Transistor Application SWITCHING
Power - Max 2W
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Terminal Finish MATTE TIN
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
