TIP29B
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN Non-RoHS Compliant Bipolar (BJT) Transistor 15 @ 1A 4V 1A 2W 3MHz
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.6688
≥100 USD $0.6336
≥500 USD $0.5984
≥1000 USD $0.58432
Inventory: 544
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220AB
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Power - Max 2W
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 15 @ 1A 4V
Current - Collector Cutoff (Max) 300μA
Vce Saturation (Max) @ Ib, Ic 700mV @ 125mA, 1A
Voltage - Collector Emitter Breakdown (Max) 80V
Current - Collector (Ic) (Max) 1A
Frequency - Transition 3MHz
Compliance
RoHS Status Non-RoHS Compliant
