TIP112 image
Favorite
RoHS
RoHS RoHS compliant
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description TO-220-3 Through Hole NPN - Darlington ROHS3Compliant Bipolar (BJT) Transistor 1000 @ 1A 4V 2A 2W 100V
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.8712
≥100 USD $0.8272
≥500 USD $0.7744
≥1000 USD $0.7568
Inventory: 193
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Current - Collector (Ic) (Max) 2A
Voltage - Collector Emitter Breakdown (Max) 100V
Vce Saturation (Max) @ Ib, Ic 2.5V @ 8mA, 2A
Current - Collector Cutoff (Max) 2mA
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 1A 4V
Transistor Type NPN - Darlington
Power - Max 2W
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Operating Temperature 150°C TJ

Physical

Supplier Device Package TO-220AB
Package / Case TO-220-3
Mounting Type Through Hole
