KSC838YTA
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole NPN SINGLE Bipolar (BJT) Transistor 120 @ 2mA 12V 30mA 250mW 250MHz
PDF
/
Inventory: 8829
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Box (TB)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT APPLICABLE
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
JESD-30 Code O-PBCY-T3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Power - Max 250mW
Transistor Application AMPLIFIER
Polarity/Channel Type NPN
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 2mA 12V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 400mV @ 1mA, 10mA
Voltage - Collector Emitter Breakdown (Max) 30V
Current - Collector (Ic) (Max) 30mA
Transition Frequency 250MHz
Frequency - Transition 250MHz
Compliance
RoHS Status ROHS3 Compliant
