RoHS
/
Package TO-225AA, TO-126-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN SINGLE Bipolar (BJT) Transistor 30 @ 10mA 5V 4A 36W 3MHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.666864
≥100 USD $0.484
≥500 USD $0.404413
≥1000 USD $0.344186
≥3000 USD $0.306539
Inventory: 4090
Minimum: 1
-
+
Technical Details
Technical
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 10mA 5V
Current - Collector Cutoff (Max) 100μA
Vce Saturation (Max) @ Ib, Ic 600mV @ 200mA, 2A
Power - Max 36W
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 240
Terminal Position SINGLE
Terminal Finish TIN LEAD
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Operating Temperature 150°C TJ
Frequency - Transition 3MHz
Transition Frequency 3MHz
Current - Collector (Ic) (Max) 4A
Voltage - Collector Emitter Breakdown (Max) 45V
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-225AA, TO-126-3
Mounting Type Through Hole
Compliance
RoHS Status Non-RoHS Compliant
