BC307CBU
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
SMALL SIGNAL BIPOLAR TRANSISTOR
PDF
/
Inventory: 4218
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Bulk
JESD-609 Code e3
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Additional Feature LOW NOISE
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT APPLICABLE
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Pin Count 3
JESD-30 Code O-PBCY-T3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Power - Max 500mW
Transistor Application SWITCHING
Polarity/Channel Type PNP
Transistor Type PNP
DC Current Gain (hFE) (Min) @ Ic, Vce 380 @ 2mA 5V
Current - Collector Cutoff (Max) 15nA
Vce Saturation (Max) @ Ib, Ic 500mV @ 5mA, 100mA
Voltage - Collector Emitter Breakdown (Max) 45V
Current - Collector (Ic) (Max) 100mA
Transition Frequency 130MHz
Frequency - Transition 130MHz
Compliance
RoHS Status ROHS3 Compliant
