DTC143TKAT146
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single, Pre-Biased
Description
TRANS PREBIAS NPN 200MW SMT3
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.11264
≥100 USD $0.055
≥500 USD $0.045866
≥1000 USD $0.031865
Inventory: 12033
Minimum: 1
-
+
Technical Details
Technical
Operating Supply Voltage 50V
Number of Elements 1
Polarity NPN
Element Configuration Single
Power Dissipation 200mW
Transistor Application SWITCHING
Transistor Type NPN - Pre-Biased
Max Output Current 100mA
Pin Count 3
Base Part Number DTC143
Time@Peak Reflow Temperature-Max (s) 10
Current Rating 100mA
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 200mW
Voltage - Rated DC 50V
Subcategory BIP General Purpose Small Signal
HTS Code 8541.21.00.75
Additional Feature BUILT-IN BIAS RESISTOR
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2009
Packaging Tape & Reel (TR)
Continuous Collector Current 100mA
Resistor - Base (R1) 4.7 k Ω
hFE Min 100
Emitter Base Voltage (VEBO) 5V
Frequency - Transition 250MHz
Max Breakdown Voltage 50V
Transition Frequency 250MHz
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 150mV @ 250μA, 5mA
Current - Collector Cutoff (Max) 500nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 1mA 5V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 50V
Physical
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
