DTA015EEBTL
RoHS
RoHS compliant
RoHS compliantPackage SC-89, SOT-490
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single, Pre-Biased
Description
TRANS PREBIAS PNP 50V 0.15W SC89
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.027926
≥1 USD $0.027926
≥200 USD $0.010807
≥500 USD $0.010427
≥1000 USD $0.01024
Inventory: 931
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Resistor - Emitter Base (R2) 100 k Ω
Continuous Collector Current -100mA
Resistor - Base (R1) 100 k Ω
hFE Min 80
Frequency - Transition 250MHz
Max Breakdown Voltage 50V
Transition Frequency 250MHz
Max Frequency 250MHz
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 150mV @ 500μA, 5mA
DC Current Gain (hFE) (Min) @ Ic, Vce 80 @ 5mA 10V
Max Collector Current 20mA
Collector Emitter Voltage (VCEO) 150mV
Transistor Type PNP - Pre-Biased
Transistor Application SWITCHING
Element Configuration Single
Polarity PNP
Number of Elements 1
Output Voltage -70mV
JESD-30 Code R-PDSO-F3
Terminal Form FLAT
Terminal Position DUAL
Max Power Dissipation 150mW
Additional Feature BUILT IN BIAS RESISTANCE RATIO IS 1
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Packaging Tape & Reel (TR)
Physical
Transistor Element Material SILICON
Weight 29.993795mg
Package / Case SC-89, SOT-490
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
