DSC9A01S0L
RoHS
RoHS compliant
RoHS compliantPackage SC-89, SOT-490
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN Single Bipolar (BJT) Transistor 600 @ 2mA 10V 1muA 125mW 150MHz
PDF
/
Inventory: 3154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-89, SOT-490
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2010
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
HTS Code 8541.21.00.75
Max Power Dissipation 125mW
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DSC9A01
Number of Elements 1
Element Configuration Single
Transistor Application AMPLIFIER
Gain Bandwidth Product 150MHz
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 40V
Max Collector Current 50mA
DC Current Gain (hFE) (Min) @ Ic, Vce 600 @ 2mA 10V
Current - Collector Cutoff (Max) 1μA
Vce Saturation (Max) @ Ib, Ic 200mV @ 1mA, 10mA
Collector Emitter Breakdown Voltage 40V
Max Frequency 150MHz
Transition Frequency 150MHz
Collector Emitter Saturation Voltage 200mV
Max Breakdown Voltage 40V
Collector Base Voltage (VCBO) 50V
Emitter Base Voltage (VEBO) 15V
hFE Min 400
Dimensions
Height 600μm
Length 1.6mm
Width 850μm
Compliance
RoHS Status RoHS Compliant
