DSC5A01T0L
RoHS
RoHS compliant
RoHS compliantPackage SC-85
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN Single Bipolar (BJT) Transistor 1000 @ 2mA 10V 50mA 150mW 150MHz
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.1349
≥1 USD $0.1349
≥10 USD $0.1102
≥100 USD $0.10735
≥500 USD $0.10355
≥1000 USD $0.1007
Inventory: 2949
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 1.25mm
Length 2mm
Height 800μm
Technical
Continuous Collector Current 50mA
hFE Min 400
Emitter Base Voltage (VEBO) 15V
Collector Base Voltage (VCBO) 50V
Max Breakdown Voltage 40V
Collector Emitter Saturation Voltage 200mV
Transition Frequency 150MHz
Max Frequency 150MHz
Collector Emitter Breakdown Voltage 40V
Vce Saturation (Max) @ Ib, Ic 200mV @ 1mA, 10mA
Current - Collector Cutoff (Max) 1μA
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 2mA 10V
Max Collector Current 50mA
Collector Emitter Voltage (VCEO) 40V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 150MHz
Transistor Application AMPLIFIER
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PDSO-F3
Base Part Number DSC5A01
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Terminal Position DUAL
Max Power Dissipation 150mW
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 85
Package / Case SC-85
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
