DSC250100L
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 20V 500MA MINI3
PDF
/
Buying Options
Total Price: USD $10.7
Unit Price: USD $10.6989
≥1 USD $10.6989
≥10 USD $8.77895
≥100 USD $8.5044
≥500 USD $8.22985
≥1000 USD $7.9553
Inventory: 1265
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Cut Tape (CT)
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
HTS Code 8541.21.00.75
Max Power Dissipation 200mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DSC2501
Number of Elements 1
Element Configuration Single
Transistor Application AMPLIFIER
Gain Bandwidth Product 150MHz
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 20V
Max Collector Current 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 500mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 400mV @ 20mA, 500mA
Collector Emitter Breakdown Voltage 20V
Max Frequency 150MHz
Transition Frequency 150MHz
Collector Emitter Saturation Voltage 400mV
Max Breakdown Voltage 20V
Collector Base Voltage (VCBO) 25V
Emitter Base Voltage (VEBO) 12V
hFE Min 200
Dimensions
Height 1.1mm
Length 2.9mm
Width 1.5mm
Compliance
RoHS Status RoHS Compliant
