DSA7102R0L
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bipolar Transistors - BJT BIPLR PW TRANS FLAT LEAD 4.5x4.0mm
PDF
/
Inventory: 5317
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-243AA
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2010
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Transistors
Max Power Dissipation 1W
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DSA7102
Number of Elements 1
Element Configuration Single
Case Connection COLLECTOR
Transistor Application AMPLIFIER
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 300mV
Max Collector Current 1A
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 100mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 300mV @ 50mA, 500mA
Collector Emitter Breakdown Voltage 80V
Max Frequency 150MHz
Transition Frequency 150MHz
Collector Emitter Saturation Voltage -300mV
Max Breakdown Voltage 80V
Frequency - Transition 150MHz
Collector Base Voltage (VCBO) -80V
Emitter Base Voltage (VEBO) -5V
hFE Min 120
Dimensions
Height 1.5mm
Length 4.5mm
Width 2.5mm
Compliance
RoHS Status RoHS Compliant
