2SD2420AP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 80V 4A TO-220D
PDF
/
Inventory: 5275
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Frequency - Transition 20MHz
Transition Frequency 20MHz
Current - Collector (Ic) (Max) 4A
Voltage - Collector Emitter Breakdown (Max) 80V
Vce Saturation (Max) @ Ib, Ic 4V @ 20mA, 5A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 500μA
DC Current Gain (hFE) (Min) @ Ic, Vce 4000 @ 3A 3V
Transistor Type NPN - Darlington
Polarity/Channel Type NPN
Transistor Application AMPLIFIER
Power - Max 2W
Case Connection ISOLATED
Configuration DARLINGTON WITH BUILT-IN DIODE AND RESISTOR
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
HTS Code 8541.29.00.95
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2004
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
