2SD12110R
RoHS
/
Package TO-226-3, TO-92-3 Long Body
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 120V 0.5A TO-92L
PDF
/
Inventory: 9112
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 Long Body
Supplier Device Package TO-92L-A1
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Published 2003
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 120V
Max Power Dissipation 1W
Current Rating 500mA
Power - Max 1W
Transistor Type NPN
Collector Emitter Voltage (VCEO) 1V
Max Collector Current 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 130 @ 150mA 10V
Vce Saturation (Max) @ Ib, Ic 1V @ 30mA, 300mA
Collector Emitter Breakdown Voltage 120V
Voltage - Collector Emitter Breakdown (Max) 120V
Current - Collector (Ic) (Max) 500mA
Max Breakdown Voltage 120V
Frequency - Transition 200MHz
Compliance
RoHS Status Non-RoHS Compliant
