2SD11490SL
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 100V 0.02A MINI 3P
PDF
/
Inventory: 9921
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Technical
Frequency - Transition 100MHz
Max Breakdown Voltage 100V
Current - Collector (Ic) (Max) 20mA
Voltage - Collector Emitter Breakdown (Max) 100V
Collector Emitter Breakdown Voltage 100V
Vce Saturation (Max) @ Ib, Ic 200mV @ 1mA, 10mA
Current - Collector Cutoff (Max) 1μA
DC Current Gain (hFE) (Min) @ Ic, Vce 600 @ 2mA 10V
Max Collector Current 20mA
Collector Emitter Voltage (VCEO) 200mV
Transistor Type NPN
Power - Max 200mW
Base Part Number 2SD1149
Current Rating 20mA
Max Power Dissipation 200mW
Voltage - Rated DC 100V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Supplier Device Package Mini3-G1
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
