2SC584800A
RoHS
/
Package SC-101, SOT-883
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN 2SC5848 Bipolar (BJT) Transistor 180 @ 2mA 10V 100mA 100mW 100MHz
PDF
/
Inventory: 2676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Frequency - Transition 100MHz
Max Breakdown Voltage 50V
Current - Collector (Ic) (Max) 100mA
Voltage - Collector Emitter Breakdown (Max) 50V
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 300mV @ 10mA, 100mA
Current - Collector Cutoff (Max) 100μA
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 2mA 10V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 300mV
Transistor Type NPN
Power - Max 100mW
Base Part Number 2SC5848
Current Rating 100mA
Max Power Dissipation 100mW
Voltage - Rated DC 50V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature 125°C TJ
Physical
Supplier Device Package ML3-N2
Package / Case SC-101, SOT-883
Mounting Type Surface Mount
Mount Surface Mount
