2SB14400RL
RoHS
/
Package TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP LF 50VCEO 2A MINI-PWR
PDF
/
Inventory: 5999
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-243AA
Supplier Device Package MiniP3-F1
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2003
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC -50V
Max Power Dissipation 1W
Current Rating -2A
Base Part Number 2SB1440
Power - Max 1W
Transistor Type PNP
Collector Emitter Voltage (VCEO) 300mV
Max Collector Current 2A
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 200mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 300mV @ 50mA, 1A
Collector Emitter Breakdown Voltage 50V
Voltage - Collector Emitter Breakdown (Max) 50V
Current - Collector (Ic) (Max) 2A
Max Breakdown Voltage 50V
Frequency - Transition 150MHz
Compliance
RoHS Status RoHS Compliant
