TIP41B
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN Single Bipolar (BJT) Transistor 15 @ 3A 4V 700muA 2W 3MHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.76912
≥100 USD $0.72864
≥500 USD $0.68816
≥1000 USD $0.67144
Inventory: 457
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
hFE Min 15
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 80V
Max Breakdown Voltage 80V
Collector Emitter Saturation Voltage 1.5V
Transition Frequency 3MHz
Collector Emitter Breakdown Voltage 80V
Vce Saturation (Max) @ Ib, Ic 1.5V @ 600mA, 6A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 700μA
DC Current Gain (hFE) (Min) @ Ic, Vce 15 @ 3A 4V
Max Collector Current 6A
Collector Emitter Voltage (VCEO) 80V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 3MHz
Transistor Application SWITCHING
Case Connection COLLECTOR
Power Dissipation 2W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number TIP41
Time@Peak Reflow Temperature-Max (s) 40
Frequency 3MHz
Current Rating 6A
Peak Reflow Temperature (Cel) 260
Max Power Dissipation 2W
Voltage - Rated DC 80V
Subcategory Other Transistors
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Weight 1.214g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
