TIP32C
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole PNP Single Bipolar (BJT) Transistor 10 @ 3A 4V 3A 2W 3MHz
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.2728
≥1 USD $0.2728
Inventory: 1214
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.83mm
Length 10.67mm
Height 6.35mm
Technical
hFE Min 10
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 100V
Frequency - Transition 3MHz
Collector Emitter Saturation Voltage -1.2V
Max Frequency 3MHz
Current - Collector (Ic) (Max) 3A
Voltage - Collector Emitter Breakdown (Max) 100V
Collector Emitter Breakdown Voltage 100V
Vce Saturation (Max) @ Ib, Ic 1.2V @ 375mA, 3A
Current - Collector Cutoff (Max) 300μA
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 3A 4V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 100V
Transistor Type PNP
Gain Bandwidth Product 3MHz
Power - Max 2W
Power Dissipation 2W
Current 3A
Element Configuration Single
Voltage 100V
Polarity PNP
Number of Elements 1
Base Part Number TIP32
Frequency 3MHz
Current Rating -3A
Max Power Dissipation 2W
Voltage - Rated DC -100V
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2010
Packaging Tube
Operating Temperature -65°C~150°C TJ
Physical
Weight 1.214012g
Supplier Device Package TO-220AB
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
