TIP31ATU
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN Single Bipolar (BJT) Transistor 10 @ 3A 4V 300muA 2W 3MHz
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2288
≥1 USD $0.2288
Inventory: 1165
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 10
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 60V
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 1.2V @ 375mA, 3A
Current - Collector Cutoff (Max) 300μA
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 3A 4V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 60V
Transistor Type NPN
Gain Bandwidth Product 3MHz
Power Dissipation 2W
Element Configuration Single
Number of Elements 1
Base Part Number TIP31
Frequency 3MHz
Current Rating 3A
Max Power Dissipation 2W
Voltage - Rated DC 60V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature 150°C TJ
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 3 days ago)
