TIP126TU
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP DARL 80V 5A TO-220
PDF
/
Buying Options
Total Price: USD $4.6
Unit Price: USD $4.60275
≥1 USD $4.60275
≥10 USD $3.7772
≥100 USD $3.65845
≥500 USD $3.54065
≥1000 USD $3.42285
Inventory: 5006
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 1.214g
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Other Transistors
Voltage - Rated DC -80V
Max Power Dissipation 2W
Current Rating -5A
Base Part Number TIP126
Number of Elements 1
Polarity PNP
Element Configuration Single
Power Dissipation 2W
Transistor Application SWITCHING
Transistor Type PNP - Darlington
Collector Emitter Voltage (VCEO) 80V
Max Collector Current 5A
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 3A 3V
Current - Collector Cutoff (Max) 2mA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 4V @ 20mA, 5A
Collector Emitter Breakdown Voltage 80V
Collector Emitter Saturation Voltage 2V
Collector Base Voltage (VCBO) -80V
Emitter Base Voltage (VEBO) -5V
hFE Min 1000
Dimensions
Height 9.4mm
Length 10.67mm
Width 4.83mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
